tuya WIFI GSM smart Alarm System home Security Burglar kit 4.3 inch touch screen Support Tuya applications
NEW Upgrate WIFI GSM Alarm System (Tuya version)
This is a very Good to use home security alarm system, it is different from the old models. It is a touch screen (4.3″ TFT color model), which is very convenient to operate. It is small in size and takes up very little space.
It supports Tuya apps. And there are 10 built-in languages that can be set.
Support downloading the Tuya APP to control the host.a regular SIM card supporting 2G/GSM, and a Wi-Fi 802.11 b/g/n(2.4GHz) network connection.
This host support several alarm types, when alarm occurs, will send the SMS messages which include the detector name and the alarm number to the mobile phone users , push the alarm information to mobile Tuya app, send the alarm SMS to network alarm center, and dial the phone number at the same time, user can do field monitoring and remote control after connected.
Product advantages:
1. 4.3”TFT color full touching screen,State magnetic paste, date and time display, main interface clearly.
2. Wifi/GSM networking alarm system
3. Support Tuya application, and can network with other products supporting Tuya to form a complete smart home system.The host can be set and controlled by APP, supporting IOS/Android
4. When alarm occurred, the hub sends push notifications to your phone. After that, the hub will also make phone calls to each pre-set phone number.
5. Built in 10 languages can be set,Can set the language:Chinese, English, Russian, German, Spanish, Polish, Greek, Italian, French, Portuguese.
6. Contains RFID tag，RFID tags are easy to carry,Easy to use,Tap RFID tag reader zone to arm and disarm.
7. With two-way calling (PHONE FUNCTION)
8. Small size, only takes up very little space.
Accurate Alerts & Remote alarm notification
If thieves invade, When alarm occurred, the hub sends push notifications to your phone. After that, the hub will also make phone calls to each pre-set phone number. Support 5 groups alarm phone number setting.
Mobile app instant view the door/window open or close
Prevent children from running out of the house
Expand Your Security System Any Time
This security systems are capable of supporting 100 wireless accessories to suit your needs precisely.
A comprehensive smart home security alarm system ensures the safety of every user’s life and property. The smart home alarm system consists of an host and various front-end detectors/sensor. Front-end detectors can be divided into door sensor,PIR motion sensor, smoke detector,Gas leak detector,Alarm Siren and other equipment.
You can click on the picture to buy accessories
Supported Two Way Communication
Built-in HD microphone and voice speaker
Two way intercom system allows you to communicate with your loved ones while you are away.
When a security breach occurs, it can also long-distance intercom monitoring & shouting deterrence
SOS button
Host has SOS button,Use in case of emergency.After clicking,The alarm sounds and sends an alert notification to registered users.
Users can operate alarm host by any ways as below:
Remote controller ,Touch screen , RFID cards , Tuya APP.
Time arm/disarm
User can use their time table, to set the time auto arm and time auto disarm, avoid to repeat daily or forgot the operation.
Tamper switch & Built-in backup battery
The tamper switch (lever underneath the bracket) will trigger an alarm notification if an attempt is made to remove the hub from its installed location.
Built-in backup battery, it can stand by for 8 hours if the external power is off，and it can still work about 8 hours.(built-in siren.)
TECHNICAL PARAMETER
Display: 4.3”TFT color full touching screen
Input Voltage: DC5V(micro USB standard connector supply)
Operating current: screen off<120mA, screen on<240mA
Standby current：<80uA
Siren output：<500mA
Wireless Frequency：433Mhz
Wireless code：eV1527
GSM system：850/900/1800/1900MHz
WIFI system：IEEE802.11b/g/n wireless standard (2.4G)
Spare battery：3.7V/500mAh Li battery
Operating temperature：0~55℃
Relative humidity：<80%（no condensation）
Product size：160 x 98 x 19 mm（Length x Height x thickness)
Products real show
Package include
Set A
1 * Alarm panel
2 * Remote Control
2 * RFID tag
1 * Door&Window Sensor
1 * PIR Motion Detector
1 * Wired Siren
1 * User manual
Set B
1 * Alarm panel
2 * Remote Control
2 * RFID tag
5 * Door&Window Sensor
2 * PIR Motion Detector
1 * Wireless Siren
1 * 1080P IP Camera
1 * User manual
Set C
1 * Alarm panel
2 * Remote Control
2 * RFID tag
3 * Door&Window Sensor
2 * PIR Motion Detector
1 * Wired Siren
1 * User manual
Set D
1 * Alarm panel
2 * Remote Control
2 * RFID tag
3 * Door&Window Sensor
3 * PIR Motion Detector
1 * Wired Siren
1 * 1080P IP Camera
1 * User manual
Set E
1 * Alarm panel
2 * Remote Control
2 * RFID tag
3 * Door&Window Sensor
3 * PIR Motion Detector
1 * Wired Siren
1 * Smoke Detector
1 * User manual
Set F
1 * Alarm panel
2 * Remote Control
2 * RFID tag
10 * Door&Window Sensor
6 * PIR Motion Detector
1 * Lpg Gas Detector
1 * Solar outdoor Siren
1 * Smoke Detector
1 * 1080P IP Camera
1 * User manual
Set G
1 * Alarm panel
2 * Remote Control
2 * RFID tag
15 * Door&Window Sensor
10 * PIR Motion Detector
1 * Solar outdoor Siren
1 * Smoke Detector
1 * 1080P IP Camera
1 * User manual
Set H
1 * Alarm panel
2 * Remote Control
2 * RFID tag
10 * Door&Window Sensor
6 * PIR Motion Detector
1 * Wireless keypad
1 * Wireless Siren
1 * Smoke Detector
1 * 1080P IP Camera
1 * User manual
Set I
1 * Alarm panel
2 * Remote Control
2 * RFID tag
8 * Door&Window Sensor
3 * PIR Motion Detector
1 * Wireless Siren
1 * 1080P IP Camera
1 * Lpg Gas Detector
1 * User manual
Set J
1 * Alarm panel
2 * Remote Control
2 * RFID tag
10 * Door&Window Sensor
4 * PIR Motion Detector
1 * Solar outdoor Siren
1 * Smoke Detector
1 * User manual
Set K
1 * Alarm panel
2 * Remote Control
2 * RFID tag
8 * Door&Window Sensor
3 * PIR Motion Detector
1 * Wired Siren
1 * 1080P IP Camera
1 * Smoke Detector
1 * User manual
If there is no configuration you want in the Set, please contact us and we can customize it for you.
Customers of custom accessories please select “customize Set”。After submitting the order, please wait for us to modify the corresponding price before you pay!
Smart Connection
Can link with Alexa or Google Assistant to realize voice control.
Tuya smart device Experience plan
Participate and experience Tuya smart devicesin use, After the buyer downloads the Tuya APP, we will provide the account and password of the Tuya APP so that the buyer can have a more comprehensive operating experience and understanding of the product.
Account: mfsmart@163.com
Password: 123test
Shipment
•Free shipping only means free shipping cost, don’t take any responsilbe of any other custom tax.
•The transportation process is completed by the logistics company.If you have not received your shipment within 60-90 days from payment, please contact with us. We will track the shipment and give a reply to you as soon as possible. Our goal is customer satisfaction!
Warranty
•1 Years replacement warranty.
•We benefit for all item sale. If you need help and have any other question , please feel free to contact us by message .
Feedback:
•Your Positive feedback and all 5 stars are important to us which encourage us to do better and support best service and good product for all clients .Thanks in advance for you leaving positive feedback and 5 stars.
•Please don’t leave negative feedback and low score, because that won’t solve problems. Please give us an opportunity to service you again .
Thanks for your visit and welcome to visit us again!
SPECIFICATIONS
- Brand Name: awaywar
- Smart home platform: Tuya
- Origin: CN(Origin)
- Certification: CE
- Certification: RoHS
- Kit Configuration: Door/Window Sensor
- Power: AC110-240V & DC 5V
- Output Number: *
- Video Interface: No
- Display: Yes
- Alarm Type: The Alarm
- Alarm Type: SMS
- Alarm Type: PSTN
- Alarm Type: Apps Control
- Size: 160 x 98 x 18 mm
- Model Number: MF-07
- Password Keyboard: Yes
- Arming Type: APP
- Connection Type: wireless
- Zone Number: *
- Supported applications: Tuya APP
- Display: 4.3 inch touch screen
- Support network: GSM / WIFI
- Input Voltage: DC5V(micro USB standard connector supply)
- Operating current: screen off<120mA, screen on<240mA
- Standby current: <80uA
- Siren output: <500mA
- Wireless Frequency: 433MHz
- Wireless code: eV1527
- GSM system: 850/900/1800/1900MHz
- WIFI system: IEEE802.11b/g/n wireless standard (2.4G)
- Spare battery: 3.7V/500mAh Li battery
- Operating temperature: -10 ~ 55℃
- Relative humidity: <80%(no condensation)
- Product size: 160 x 98 x 18 mm
- Product type: Burglar Alarm System
- Product type 2: Security alarm
- Feature1: humanized menu
- Feature2: Easy to use and install
- Feature3: anti-tamper
- Feature4: 4.3 inch touch screen
- Feature5: Ultra-slim Process Design
- Feature6: Home Security Protection Alarm System
- Feature7: Support Mobile phone app
- Feature8: Contains RFID tag
- Feature9: Host has SOS button
